RFID READER MODULE WITH 4 SAM SOCKETS
– High End Performance
– 4 SAM sockets (ID000 Format); tested according to EMVCo Contact Level 1
– Operation with internal and external antenna
(integrated antenna multiplexer)
– High density of integration / compact design
– ISO 14443 / ISO 15693 / ISO 18000-3M3
– Supports NFC applications
– RS232-TTL and USB interface
Variable Multitag Read /Write device
ID CPR74 is a 13.56 MHz Proximity Read /Write device supporting transponders according to ISO 14443 Type A and Type B,
ISO 15693, ISO 18000-3M3 as well as NFC devices according to
ISO 18092.
The Reader Module is certifiable for applications like VDV-KA
and ITSO. The 4 SAM sockets are tested according to EMVCo
Contact Level 1.
Compact design and two alternatively usable interfaces
(RS232-TTL or USB) enable an easy integration in terminals,
housings and other devices.
Comfort and Safety for your application
Due to the integrated antenna multiplexer the internal antenna
can be operated with an additional external antenna. The
reader mode “Scan-Mode” allows an automatic switch between
both antennas.
The SoftCrypto and SAMCrypto High-Level-Functions offer a
comfortable and fast interface for access to encrypted data of
mifare DESFire (EV0, Ev1), mifare PLUS and mifare Ultralight C.
Convenient access to newer chips such as mifare DESFire EV2
or NTAG 424 DNA via a secure communication channel.
TWO READING POINTS IN ONE DEVICE
Operation with integrated and external antenna (integrated multiplexer),
for example in vending machines or onboard-computers in buses and trains
